Grade Upgrade

Grade Upgrade

Has the development of new tool materials already reached its peak and is experiencing stagnation? Find out more from Andrei Petrilin and Marcel Elkouby, ISCAR.

Grade Upgrade

Fig 1: CBN grade IB20H insert for hard part turning.‎

Building a house begins with laying the foundation. The strength and the reliability of the whole house depends on how strong the foundation is. In cutting tool engineering, this foundation is a cutting material.

There are various types of cutting materials: cemented carbide, polycrystalline diamond, high speed steel, and ceramics, to name a few. Each type contains different grades. At various stages in metal cutting history, the introduction of each cutting material and its use has led to a significant change in the level of cutting speeds and, consequently, productivity. However, if the previous century, especially its second half, was marked by the rapid progress of tool materials, today we do not see any significant new solutions in this field. Does this mean that the development of new tool materials has already reached its peak and is experiencing stagnation?

Of course not. It is simply that the new developments are deep within the cutting material and are focused on its structure, and can be observed only with the help of scanning electron microscopy (SEM), X-ray diffraction (XRD), electron backscatter diffraction (EBCD), and other sophisticated methods. They cover a tremendously complicated world of coatings that is extremely diverse despite its very small thickness, measured only by microns.

Cemented Carbide

Grade Upgrade

Fig 2: Parting tool carrying IC1010 grade insert‎.

The most commonly available cutting material today is cemented carbide (primarily coated), also known as ‘hard metal’, ‘tungsten carbide’ or simply, carbide. In terms of performance, it represents a reasonable balance between efficiency, tool life and cost. A combination of cemented carbide, coating, and post-coating treatment produces a carbide grade. Only one of these components—the cemented carbide—is an essential element in the grade. The others are optional.

Cemented carbide is a composite material comprising hard carbide particles that are cemented together by binding metal (mainly cobalt). Most cemented carbides used for producing cutting tools integrate wear-resistant coatings. There are also various treatment processes that are applied to already coated cemented carbide (for example, the rake surface of an indexable insert). New developments in cemented carbide, as a tool material, are concentrated in three directions: carbide production technologies, advanced coating methods, and innovative post-coating techniques. Considerable success has been achieved in each of these directions; this is reflected in the wealth of new products introduced to the market by leading cutting tool manufacturers.

Cutting tool customers might analyze the grades using parameters such as productivity, tool life, and performance. Indeed, the question of how a new product was created to meet customer requirements fades into the background as applicability and efficiency form the main measure of progress from the customer’s  point of view.

Upgrading Carbide Grades

In upgrading carbide grades, ISCAR is very sensitive to a challenge faced by the metalworking industries. In this context, ISCAR’s tool material solutions—developed considering the trends of modern metalworking—can be quite indicative. Take, for example, difficult-to-cut materials such as titanium and heat-resistant steels and exotic superalloys. Recently, the share of their application in industry has increased significantly. Along with the aircraft industry, a traditional consumer of these materials, they may be increasingly found in power engineering, automotive, and oil and gas branches. The growing usage of the materials demands technological solutions, including machinery and cutting tools. The new tools require an appropriate foundation, made of advanced cutting tool materials,  to achieve the desired cutting geometry. And for the construction of this foundation, ISCAR offers its new effective ‘bricks’—upgraded carbide grades.



To continue reading this article, head on over to our Ebook!

For other exclusive articles, visit www.equipment-news.com.
